1. Select Fax Test from diagnosis mode.
2. Select Modem Setting.
3. Use arrow keys to select a menu to test and press Select key. The categories that can be tested from
Fax Setting are the followings.
Categories
Range
Default
Select Country
Korea
Dial Timeout
30s ~ 180s
59
Transmit Level
-35dB ~ 0dB
-11
Receive Threshold
-50dB ~ -16dB
-43
DTMF Low Level
-15dB ~ -1dB
-10
DTMF High Level
-15dB ~ -1dB
-7
Pulse Make Time
20ms ~ 50ms
32
Pulse Break Time
50ms ~ 80ms
64
Pulse Dial Type
Normal, Pulse One, Ten Minus
Normal
Interdigit Delay
600ms ~ 1000ms
850
DC Characteristic
DC1, DC2, DC3, DC4
DC2
Impedance
600, Complex, 540
600
Caller ID Pattern
FSK
FSK
Busy Tone Cycles
1 ~ 10
3
Busy Tone Min On Time
1 ~ 255
45
Busy Tone Max On Time
1 ~ 255
55
Busy Tone Min Off Time
1 ~ 255
45
Busy Tone Max Off Time
1 ~ 255
55
Extension Support
Enable, Disable
Disable
Pulse Fall Time
Fast, Slow
Fast
Extension Voltage Treshold
Enable, Disable
Disable
4. Press OK to save settings.
5. To exit, press Return.
