Sindoh M401 - Front Part; Main Board; Pdu

Front Part
Main Board
1. Remove the rear cover of the machine.
2. Open the front door and remove the left cover.
3. Separate 15 harnesses from the connector and 4 bolts and the main board.
 Be careful not to disconnect harness wires when removing the harness from the connector.
 When disassemble, take caution on paths to use it on re-assemble.
PDU
1. Remove the rear cover and open the front cover.
2. Remove the right cover.
3. Remove 8 bolts.
