Sindoh M401 - Option Tray Unit Cover Removal

6. Remove bushings on shaft’s both ends and E-Ring to remove arm from the shaft.
7. Pick up roller and idle roller can be removed and replaced.
Option tray Unit Cover Removal
1. Take the tray cassette out and separate feeding unit from the machine.
Before removing the tray unit from the machine, the machine’s power must be turned off.
2. Separate the tray unit and remove 4 screws.
