Sindoh M401 - Inlet + Ac Sw; Heater

Pin Array
1. INLET + AC SW
Connector
No.
Connector Name
Manufacturer
INLET
0707-1-C7D
INALWAYS
AC SW
3024- P2T7SBKBK
(SPST)
CHILY
2. Heater Connector
Connector
No.
Connector
Name
Pin
No.
Signal Name
CN101
HEATER
CONNECTOR
1744056-3
(AMP)
1
HEATER_L
2
(removed)
3
HEATER_N
* Spacing for no. 2 pin from total of 3 pins (to secure isolation distance)
