Sindoh M401 - Fusing Unit Removal

Fusing Unit
Fusing Unit Removal
 Before proceeding with any procedures in this section, turn the main power switch off and wait
until the Fusing Unit cools down. You can get burn from the Fusing unit.
 Turn the main power switch off.
1. Open the front door
2. Remove the rear cover.
3. Remove 2 screws [A].
4. Separate 3 connectors in red circles.
