Sindoh M401 - ADF Exterior Cover; ADF Front Cover

To Next Page

To Previous Page

ADF Exterior Cover

ADF Front Cover

1. Lift ADF assembly up.

2. Unlock 3 hooks.

3. Open ADF’s top cover and remove ADF’s front cover.

ADF Rear Cover

1. Open ADF’s top cover.

2. Unlock 2 hooks.
