1. Open the front door and remove left and right covers from frame.
2. Remove the upper cover.
3. Hold the [A] part on the cooling fan and remove it from frame.
When reassembling the cooling fan, make sure to adjust to correct left and right sides.
4. Remove the cooling fan harness connected to CN25 connector from system card.
