Paper Detection Sensor
1. Separate the feeder and remove one screw at the bottom of the machine to remove it.
Manual Paper Tray (MPT)
1. Open the front door and disconnect the link connected with the machine.
2. Push the front door to the left to remove it from the machine.
3. Remove 2 screws to separate door open shaft.
