Sindoh M401 - Left Cover

2. Remove 4 bolts and pull it out forward to remove the back door and cover from main body.
 When removing rear cover from the main body, be careful not to damage 4 hooks inside
the cover.
Left Cover
1. Remove rear door and cover from the main body.
2. Remove the bolt in above figure.
3. Unlock 4 hooks at the bottom of the machine and lift the cover up to remove it from the machine.
