9
COM1
GND
10
DT2P
LD2 image data LVDS + Differential signal
11
DT2N
LD2 image data LVDS - Differential signal
12
COM1
GND
13
SHK1
LD1 AUTO Power Control signal
14
SHK2
LD2 AUTO Power Control signal
15
ENBK
Laser Diode enable signal
16
VREF_K1
LD1 luminous energy setting VREF1 power
17
VREF_K2
LD2 luminous energy setting VREF2 power
18
COM1
GND
9. SYSTEMCARD-HVPS & LVPS IF (CN40)
NO.
Signal
Description
1
TX_SENSING
Transfer F/B signal
2
TX_ENB
Transfer Enable signal
3
TX_PWM
Transfer output signal
4
CHGPWM
Electrification output signal
5
DEVPWM
Development output signal
6
+24V
HVPS supply +24V power
7
COM1
GND
8
+24V
PDU +24V supply power
9
+24V
PDU +24V supply power
10
COM1
GND
11
COM1
GND
12
+5VIN
PDU +5V supply power
13
COM1
GND
14
HR_PSU
Fusing heater On/Off control signal
10. SYSTEMCARD-THEMISTER & Fuser Exit_S (CN13)
NO.
Signal
Description
1
THERMISTER
Fusing temperature F/B signal
2
COM1
GND
3
FUSER_EXIT_S
Record delivery sensor detect signal
4
COM1
GND
5
+5V_UICC_S
Sensor Power
