Sindoh M401 - Image Cartridge

To Next Page

To Previous Page

Image Cartridge

Installation

1. Open the top front cover.

2. Hold the cartridge handle and pull it out while lifting it up toward outside.

3. Remove the cartridge wrapping.

Cartridge handle
