Sindoh M401 - Separating Main Feed Roller

To Next Page

To Previous Page

Paper Feed

Separating Main Feed Roller

1. Open the front door and separate the link.

2. Remove the left cover.

3. Remove 3 screws to separate segment gear [A] and bypass solenoid a’ssy.
