Perm Page Count (Permanent Page Count)
Permanent page count can be seen from this menu option. The permanent page count cannot be
changed from Control Panel by a user or technical engineer.
Scanner Service
FB Left Margin
To adjust scan margin,
1. Use the gradation chart on the paper’s edge to check current scan margin.
2. Select value to be changed from Top Margin and Left Margin.
3. Press the arrow keys to set desired value and press Select key.
Print margin range is like the followings and can be change with unit of 1.
Categories
Value (unit: 1/600 inch)
Image Moving Direction
FB top margin
-94 ~ + 94
+: Image moves up
FB left margin
0 ~ +22
+: Image moves left
ADF top margin
- 94 ~ +94
+: Image moves up
ADF left margin
0 ~ +22
+: Image moves right
4. Use the gradation chart on the paper’s edge to check changed margin.
5. To exit, press Return.
6. Adjust FB top margin, ADF top margin and ADF left margin identically.
FAX Service
FAX TEST
Generate Tone
7. Select Fax Test from diagnosis mode.
8. Select Generate Tone.
9. Use arrow keys to set the signal to test and press Select key.
When the signal is selected, output signal is sent and continued until stop key is pressed. The
categories that can be tested from Generate Tone are the followings.
