Sindoh M401 - Laser Unit; Structure and Optical System Path

Laser Unit
Structure and Optical System Path
< L/LF MODEL>
A : Laser Diode Unit
F : Synchro Reflection Mirror
B : Collimator Lens Unit
G : Synchro Detect Lens
C : Cylindrical Lens
H : Synchro Detect Sensor
D : Polygon Mirror Motor
J : #2 F-theta lens
E : #1 F-theta lens
K : Reflection Mirror
