Upper Cover
1. Remove the rear cover and the left and right covers from the machine.
2. Remove the Control Panel.
3. Remove 2 bolts on the top left of the frame.
4. Remove 2 bolts on the right side of the frame and lift the upper cover up to remove it from the
machine.
