5. SYSTEMCARD-FLATBED MOTOR (CN7)
NO.
Signal
Description
1
AOUT1
FB Motor’s A phase
2
AOUT2
FB Motor’s /A phase
3
BOUT1
FB Motor’s B phase
4
BOUT2
FB Motor’s /B phase
6. SYSTEMCARD-LSU (CN11)
NO.
Signal
Description
1
nHSYNC_H
Synchronization detection signal
2
GND
GND
3
+5SW
LSU_Power
4
nSH_H
SAMPLING & HOLD
5
nLDEN_H
Laser Diode enable Signal
6
nVIDEO_H
Image data signal
7
GND
GND
7. SYSTEMCARD- POLYGON MOTOR (CN8)
NO.
Signal
Description
1
nLSU_CLK_H
Standard clock supplied to polygon motor
2
nREADY_H
Polygon motor constant speed reaching signal
3
nSTART_H
Polygon motor’s start signal
4
GND
GND
5
+24V
+24V power
8. SYSTEMCARD-LSU_2BEAM (CN48)
NO.
Signal
Description
1
COM1
GND
2
nHSYNC_H
Synchronization detection signal
3
COM1
GND
4
+5SW
LSU_Power
5
+5SW
LSU_Power
6
COM1
GND
7
DT1P
LD1 image data LVDS + Differential signal
8
DT1N
LD1 image data LVDS - Differential signal
