20. SYSTEMCARD- EMPTY_MPT_S (CN24)
NO.
Signal
Description
1
EMPTY_S
Tray paper detection signal
2
COM1
GND
3
+5V_UICC_S
Sensor Power
4
MPT_S
MPT paper detection signal
5
COM1
GND
6
+5V_UICC_S
Sensor Power
21. SYSTEMCARD- INPUT_S (CN36)
NO.
Signal
Description
1
INPUT_S
Paper feed detection signal
2
COM1
GND
3
+5V_UICC_S
Sensor Power
22. SYSTEMCARD- SB1 & SB2 _S (CN18)
NO.
Signal
Description
1
COM1
GND
2
SB2
ADF paper feeding sensor
3
SB1
ADF paper fixing sensor
4
+5V_UICC_S
Sensor Power
23. SYSTEMCARD- FB HOME_S (CN20)
NO.
Signal
Description
1
FB_HOME_S
CIS home position on FB sensor signal
2
COM1
GND
3
+5V_UICC_S
Sensor Power
24. SYSTEMCARD- ADF_Cover open (CN46)
NO.
Signal
Description
1
COM1
GND
2
ADF_Cover_SW
ADF cover switch On signal
