Section 12 Scope Multimeter
The Scope Multimeter function allows you to perform multiple types
of circuit and component measurement tests. This chapter includes
general operation procedures, instructions for saving and
reviewing test data, optional settings, and general reference
information.
Main Topic Links
• Safety Information page 96
• Overview page 97
• Digital Multimeter (DMM) page 97
• Graphing Multimeter (GMM) page 98
• Lab Scope page 99
• Digital Multimeter (DMM) page 97
• Tests and Capabilities (Quick Reference) page 100
• General Information page 103
• Operation and Controls page 105
• Optional Settings page 119
• Capturing Data page 123
• Optional Settings page 119
• Reviewing Data and Using Zoom (Review Mode) page 124
• Saving Data Files page 127
• General Reference page 128
12.1 Safety Information
Over Voltage Installation Category (CAT) - This Scope Multimeter is rated
as a Category (CAT) 1 device. The maximum rated transient over voltage
impulse is 500 volts, DO NOT exceed the rated transient over voltage.
Risk of electrical shock.
• Read the Safety Information provided for important warnings on the use of
this product
• This product is intended for Measurement Category I (for example,
automotive 12V systems), do not use this product for Measurement
Categories II, III, and IV.
• Measurement Category I is for performing measurements on circuits not
directly connected to MAINS or MAINS circuits (an example of a MAINS
circuit is 120V AC or 240V AC household or industrial electricity), do not
connect this product to MAINS or MAINS circuits.
• Do not apply the Black Ground Lead to test points other than ground/
system return/vehicle chassis.
Electrical shock can cause personal injury, equipment damage, and/or circuit
damage.
WARN ING
