Scanner Features and Icons
30
NOTE
If the Scanner feature is exited during the session that Instant ID was used,
selecting Scanner again, will not ID the vehicle again. To quickly ID the vehicle
again, select it from Previous Vehicles and Data > Vehicle History.
If the vehicle is not automatically identified, follow the screen prompts to enter
the information required to identify the vehicle.
Alternative Vehicle Identification
Occasionally, you may try to identify a test vehicle that the Scanner does not
recognize, the database does not support, or has some unique characteristics that
prevents it from communicating with the Scanner. In these instances, there is an
alternate choice that allows you to establish communication with the vehicle:
OBDII/EOBD Function—this function allows you to connect to the OBDII
equipped vehicle and perform basic OBD-II or EOBD diagnostic functions, see
OBD Direct on page 84 for additional information.
6.2.5 System Selection
After the vehicle is identified, a menu of available systems and/or options is displayed
(Figure 6-4).
By default, System options are displayed by category (e.g. Engine, Transmission,
Body Controls, Instruments, etc.) (Figure 6-4). In this mode commonly used
selections are at the top of the list.
Depending on your preference, select the icon (arrow in Figure 6-4) to toggle the
display between a categorized list (Figure 6-4) and a non-categorized list
(Figure 6-5).
When a system (e.g. Engine, Antilock Brakes, etc) is selected, the diagnostic tool will
attempt to establish communication with that vehicle system, then (once connected)
will display that system’s main menu, see System Main Menu Options on page 31.
NOTE
Only the systems and options supported for the vehicle are included in the
list(s).
For Code Scan information, see Vehicle Code Scan on page 53.
Figure 6-4 Typical systems menu (categorized list)
Figure 6-5 Typical systems menu (non-categorized list)
