Service Manual
11 System Maintenance
●
Store the probe alone to avoid any impact on the probe head.
●
Carefully wind the probe cable.
●
Dry the probe before the storage.
11.3 Biopsy Bracket Maintenance
11.3.1 Cleaning, Disinfecting and Sterilizing the Biopsy Bracket
1. Remove the biopsy guide bracket from the probe, and then remove the sheath from biopsy guide.
(If using intracavitary biopsy bracket, you should detach the bracket by separating the inner part
from the top housing.)
2. Brush and rinse the biopsy bracket to remove the residue.
3. Dry the bracket with a sterile lint-free soft cloth.
4. After each use, the surface biopsy bracket and intracavitary biopsy bracket should be high-level
disinfected. For details, refer to Section 12.1.4 Disinfecting and Sterilizing the Probe.
11.3.2 Storage
Store the biopsy bracket is stored in a sterile environment.
11.4 Replacing the Fuse
Fuse
T1 T2
50CT-T3.15AH 250V
Two fuses with specifications of 50CT-T3.15AH 250V are provided
by the manufacturer. You can also purchase the fuse with the same
specifications for the fuse replacement.
You can replace the fuse with the instructions of the service personnel if
the fuse is blown.
If the fuse is blown again after a replacement, please stop using the
ultrasound system immediately and contact customer service.
11.5 Equipment Disposal
You should dispose of the main unit, the probe, the biopsy bracket or other accessories in accordance
with the local laws or regulations.
For the detailed disposal information, consult the manufacturer or the local distribution. The
manufacturer is not responsible for any system content or accessories that have been discarded
improperly.
