89
Service Manual
6 Software Installation and Upgrade
To set time and date
Set System Date and System Time in the Main menu to the current time and date.
To save settings
Highlight Save Changes and Exit, and press the Set key to save settings.
6.3.2.3 Software Installation
1. Remove the USB keyboard before the system reboot, wait for Linux self-test until the following
massage appears.
Image Recovery Version 13.5
Warning! System Recovery Starting.
Continue? (y/n)
2. Connect the USB keyboard to the specific USB port, type y or forcekill, and then press the Enter
key on the USB keyboard to install the software. The software installation needs 7-10 minutes.
NOTE:
If
FAIL
pops up during the installation process, check that kernel files in the USB drive is
complete, UPDATE folder is decompressed and the hardware parts are connected well. Type
y
or
forcekill
in the dialogue box after the above troubles are cleared, and press the
Enter
key on
the USB keyboard to re-install the software. If the software still cannot be installed, check the
USB drive or hard disk, and then re-install the software.
3. Press the Enter key when Press Enter key to shutdown appears, and the ultrasound system
automatically shuts down after exiting the USB drive system.
4. Remove the USB drive, reboot the ultrasound system.
NOTE:
If error message pops up during the start-up process, check that asecurexxxxxx.tar.gz is
consistent with the control number.
6.3.2.4 Writing in acong File
For details, refer to Section 6.5.1.
6.3.2.5 μ-Scan Key Activation
1. Insert the μ-scan key into the ultrasound system.
2. When the system displays the Exam screen, connect the USB drive written with the keypass file.
NOTE:
Ensure the keypass file is placed in the root directory of the USB drive.
3. Enable the touch-screen keyboard, tap Shift, E and press the Menu key successively. Type the
month password when the following dialogue box pops up, and then press the Enter key to
confirm.
To Next Page
