52 Service Manual
4 Parts Disassembly
The disassembled power supply is as shown in the following figure.
4.10 Ultrasound Unit Disassembly
One screwdriver is needed during the ultrasound unit disassembly.
Perform the following steps,
1. Disassemble the back cover. For details, refer to Section 4.5.2 Back Cover Disassembly.
2. Remove four screws to take out the DVD support.
