Sonoscape S30 - Hard Disk Disassembly

47
Service Manual
4 Parts Disassembly
The disassembled DVD drive is as shown in the following figure.
4.8 Hard Disk Disassembly
One screwdriver is needed during the hard disk disassembly.
Perform the following steps,
1. Disassemble the back cover. For details, refer to Section 4.5.2 Back Cover Disassembly.
2. Use the screwdriver to remove four screws.
