Spectra Precision Focus 6 User Manual

4 Applications
94 Spectra Precision Focus 6 5" Total Station User Guide
3. Sight the second point and press [MSR1] or [MSR2]. The distances between the first
and second point are displayed.
4. To change display screens, press
[DSP].
5. To record the distance and angle information as a
comment record, press
[ENT] in the 1/2 or 2/2
observation screen.
Default point numbers are displayed. You can
change these point numbers. To record a note,
press
[ENT] in the To field.
B
Tip – Data that you save in RDM functions is stored in RM records. For more information,
see RM records, page 136. When you download data in Nikon RAW format, they are
output as comment (CO) records.
Measuring between the current point and the immediately preceding
point
1. To enter the RDM (Continuous) function, press
[4]
or select
RDM(Cont.)in the Programs menu.
2. Follow the procedure as for a radial RDM
measurement. For more information, see
Measuring between the current and the first point
measured, page 93.
rSD Slope distance between two points
rVD Vertical distance between two points
rHD Horizontal distance between two points
rAZ Azimuth from first point to second point
rV% Percentage of grade (rVD/rHD) × 100%
rGD Vertical grade (rHD/rVD) :1
