14215700-IG, Edition 15.0
May 2020, Original document
165
16 Zones (16 base stations per zone)
If defining 16 zones for a site with 256 base stations (selecting 16 Zones (16 base stations per
zone) in the Zone based paging field), the numbering of base stations could be the following:
Site Zones Max. Base Stations RPN
Site 1 Zone 1 16 0 - 15
Zone 2 16 16 - 31
Zone 3 16 32 - 47
Zone 4 16 48 - 63
Zone 5 16 64 - 79
Zone 6 16 80 - 95
Zone 7 16 96 - 111
Zone 8 16 112 - 127
Zone 9 16 128 - 143
Zone 10 16 144 - 159
Zone 11 16 160 - 175
Zone 12 16 176 - 191
Zone 13 16 192 - 207
Zone 14 16 208 - 223
Zone 15 16 224 - 239
Zone 16 16 240 - 255
Note: The physical base station number in a zone can be less than 16,
but the RPN assigned to it must be within the defined RPN range. If you
move the base station to another zone, RPN must be changed accord-
ingly.
32 Zones (8 base stations per zone)
If defining 32 zones for a site with 256 base stations (selecting 32 Zones (8 base stations per
zone) in the Zone based paging field), the numbering of base stations could be the following:
Spectralink IP-DECT Server 200/400/6500 and Virtual IP-DECT Server One Installation and Configuration Guide
