SpectraLink IP-DECT SERVER 6500 - Adding Additional Spectralink DECT Media Resources

14215700-IG, Edition 15.0
May 2020, Original document
81
Adding Additional Spectralink DECTMedia Resources
The Spectralink IP-DECT Server 6500 can be upgraded with up to two additional Spectralink
DECTMedia Resources to increase speech capacity. Each Spectralink DECTMedia Resource
provides 32 media channels and is purchased separately.
Below is an image of the Spectralink IP-DECT Server 6500 cabinet. The Spectralink IP-DECT
Server 6500 itself resides to the far left, which is standard, and the two optional Spectralink
DECTMedia Resources reside in the middle and to the far right.
Note:
It is possible to have cabinets with Spectralink DECTMedia Resources only.
If Spectralink DECTMedia Resources are used in conjunction with a Spectralink Virtual
IP-DECT Server One, acquisition of a cabinet is required. The media resource cabinet
comes with one media resource print board and the possibility of installing up to two more
media resource print boards. Each Spectralink Virtual IP-DECT Server One contains 32
built in media channels if the Mandatory Base Licence ARI 150 Users 64 Base Stations
32 Media Channels | Virtual IP-DECT Server License is installed. The Spectralink Virtual
IP-DECT Server One supports a total of 1024 media channels - up to 31 media resource
print boards (11 cabinets in total).
