Configuring a Backup Spectralink IP-DECT Server 6500/Spectralink Virtual IP-
DECT Server One
On the backup Spectralink IP-DECT/Virtual IP-DECT Server only basic network settings and
redundancy settings need to be configured. All other settings are retrieved from the master Spec-
tralink IP-DECT/Virtual IP-DECT Server.
Note:
When setting up the backup server, the internal media resource is disabled as default. In
case the redundant system must use the internal media resource, this must be con-
figured under Configuration > Wireless Server > Wireless Server Configuration >
Media resources > Add new as active before configuring the backup server.
For more information about internal media resource recommendations, see "Recom-
mendations" on page31.
1. Ensure that the Redundancy License is installed, and configured with basic network settings.
License installation requires reboot of system.
2. Click Configuration, and then click Redundancy.
3. On the Redundancy Configuration page, enter the following data:
Field Setting
Redundancy Configuration - Node type
Single If selected, this will disable redundancy and configure for
stand alone (normal single server solution).
Select Single, if this device is to be a normal single
server solution.
Master If enabled, this will enable redundancy and configure the
device as master server. The system will be controlled by
this device.
Select Master, if this device is to be the master server.
Slave If enabled, this will enable redundancy and configure the
device as backup (slave) server. The device will be con-
trolled by a master server.
Select Slave, if this device is to be the backup server.
Redundancy Configuration - Peer node
