Field Setting
Secondary username (Optional) Enter a Secondary username.
Note: Allowed characters: a-z, A-Z, 0-9, -_.!~*'
()&=+$,;?/
The Secondary username can be used to make voice
calls, if the connection to the SIP PBX is lost. The Sec-
ondary username must be globally unique.
In some PBXs there is a mapping between username
and number (e.g. Username = hz2539jk, Number =
1234). If the connection to the SIP PBX is lost, then it is
possible to make the mapping internally by defining a Sec-
ondary username.
Note: The feature MUST be used with SIP setting Allow
internal routing fallback enabled. For more inform-
ation, see "Configuring SIP and IP-PBX Settings" on
page136.
Domain (Optional) Enter the domain part of a SIP URI.
Note: Allowed characters: a-z, A-Z, 0-9, .-
E.g. example.org in
John Doe<sip:1234@example.org>
Note: If not configured, the default domain entered under
SIP configuration will be used.
Displayname (Optional) Enter the name of the user (e.g. caller ID).
Note: Disallowed characters: <>\"
E.g. John Doe in
John Doe<sip:1234@example.org>
Note: If Cisco Unified CM(Advanced Features) License
is loaded, the Cisco Unified CM will not use this, but it
may ease the administration of users within the Spec-
tralink IP-DECT Server.
