2 Setup the lift equipments
The “SETUP” menu is used to adapt the control panel to your lift. It defines the lift’s system requirements as well
as the settings enabling the installation’s performance to be optimised.
All the control panels are delivered preconfigured according to the client’s datas.
The parameters with a start indication (example: « [PARAM]* ») are the default parameters
2.1 Modifying a setting
Modifying a setting is only authorised if the “PROTEC CONFIG” setting is set to “NOT PROTECTED”. If not a
message “MODIF NOT AUTH.” will appear.
To modify a setting, select it and press the “ENTER” key, the current value starts flashing. Pressing the “” or “”
keys changes its value. To validate your selection press the “ENTER” key again, the new value is saved and does
not flash. To cancel your modification press the “ESC” key.
Takes account of modifications
The modifications are not taking account while the lift is in use.
To save the modifications, press the “BACK” key several time to return to the main menu
The following message appears:
After 2 seconds, you can switch to the standard indication by pressing “BACK” key.
Take account of new settings
Wait until the lift is in an available state, ensure there is no-one remaining inside the car then
press the “RESET” key for two to three seconds. The lift restarts after initialisation with the new
settings.
2.2 Reloading factory settings
The configuration used by the control panel is saved in the DCF.txt file. Each setting modified by the console is
therefore saved in this file. In case of a problem loading the configuration or incorrect operation following a
configuration modification, you can go back to the factory settings. This configuration is backed-up in the EDS.txt
file.
To go back to the factory settings:
1) Press the “ +” button and the “ - “ button
2) Do a reset by keeping the “ +” and “ -“ buttons pressed down
3) Press the “ENTER“ key.
4) The lift control panel is configured with the factory settings
