Sprinte ASP 116 evolution - Overspeed and Temperature Faults

MANUEL D’UTILISATION « ASP 116 EVOLUTION »
MAINTENANCE
Sprinte SAS, All rights reserved, including translation rights
74
4.4.12 Overspeed
OVERSPEED
OOM
USER OPERATION
Overspeed in user operation
The car speed exceeded the value allowed in user operation
- Check your parameters in the OVERSPEED menu
- Check the inverter parameters
OOM
INSP OPERATION
Overspeed in inspection operation
The car speed exceeded the value allowed in inspection operation
- Check your parameters in the OVERSPEED menu
- Check the inverter parameters
OOM
EMCY OPERATION
Overspeed in emergency operation
The car speed exceeded the value allowed in emergency operation
- Check your parameters in the OVERSPEED menu
4.4.13 Temperature
TEMPERATURE
OO
PANEL T° > MAX T°
ou
PANEL T° < MIN T°
Exceeding operating temperature in control panel
The 216SP board is equipped with an internal temperature sensor. The control panel if put out of order if the
temperature exceeds the temperature authorised in the configuration menu
- Check the temperature indicated by the sensor menu: “DIAGNOSTIC -> TEMPERATURE - > 216SP
SENSOR”
- Check temperature threshold of control panel "CONFIGURATION ->EQUIPMENT->216SP MAX T”
OO
MACH T° > MAX T°
ou
MACH T° < MIN T°
Exceeding operating temperature in machinery
132PK external temperature sensors may be connected on MC2-M connector of 216SP board
- Check the temperature indicated by the sensor in the menu: “DIAGNOSTIC -> TEMPERATURE - >
EXT SENSOR XX”, XX equal to 1 to 3 depending on number of sensors connected
- Check temperature threshold in the configuration “CONFIGURATION ->EQUIPMENT-> MAX
MACHINE TEMP”
OO
132PK PROBE OO
Temperature probes are not responding
- Check the 132PK probes connection on MC2-M connector of 216SP
- Check that the configuration matches the number of probes connected
OO
216SP PROBE OO
The 216SP board temperature probe does not respond
- Change the 216SP board
