USER MANUAL « ASP 116 EVOLUTION »
CONFIGURATION
Sprinte SAS, All rights reserved, including translation rights
54
3.2 Configuration of special I/O of 217SP
CONFIGURATION ► I/O BOARDS ► 217SP
To assign the connectors to special functions, the following parameter must be configured:
[CONNECTOR] = [SPECIAL I/O]
ES1-X, ES2-X
ES3-X, ES4-X
[TYPE] [LEVEL]
[NOT CONNECTED]
The I/O isn’t used
[CAR AT LVL] [LVL##]
The output indicates that the car is stopped at the level and the car doors are
opened.
[STRICK.LVL] [LVL##]
Input for stricken level (input NC) : note, the fire operation must be active (see §2.17)
[ARRIV.GONG] [LVL##]
pulse output of 9 seconds to command the arrival gong (68SP type)
[FLOOR LIGH] [LVL##]
pulse output of 0.5 seconds to command the floor lighting at the car arrival
[CAR POSIT.] [LVL##]
The output indicates the car position at the slowdown
[>LVL ACCES CODE]
Activate the levels access codes.
[>BUILD.ACC.COD]
Activate the building access code.
[>H CALLS DISABLE]
Deactivation of the floor calls. This option permit to condemn a lift
[>SET OUT OF USE]
This input sets the lift out of use when activated.
All calls are cleared and the car goes to the ‘out of use’ level (cf 2.15 “BUILDING”).
Once arrived the lift is set out of use ( the fireman operation keeps priority).
[<LIFT OUT OF USE]
This output indicates the status of ‘OUT OF USE’ operation.
[BLOCK CAR] [NIVxx]
This input when activated inhibits the matching car call.
[UNBLCK CAR] [NIVxx]
This input ,when activated, enables the matching previously disabled car call, during
the timer set in INTERCOM TPO (see §2.15)
[ENB. COD NO] [NIVxx]
This normally opened input, when activated, enables the matching access code in
car. This input is effective only if parameter “LEVEL CODE ACTI. “ is set to
“EXTERNAL INPUT” (see §2.15)
[ENB. COD NC] [NIVxx]
This normally closed input, when activated, enables the matching access code in
car. This input is effective only if parameter “LEVEL CODE ACTI. “ is set to
“EXTERNAL INPUT” (see §2.15)
3.3 Configuration of floor indication
CONFIGURATION ► I/O BOARDS ► 217SP
To assign the connectors to LEVEL INDICATOR, the following parameter must be configured:
[CONNECTOR] = [LEVEL INDICATOR]
The level is in gray code
Level code output ES1-X8- ES1-X1ES1
0 0x0 0000 0000
1 0x1 0000 0001
2 0x3 0000 0011
