2.17 Fire operation
CONFIGURATION ► FIRE
This operation is used by the firemen to put the lift out of service in case of fire
TYPE
Fire operation type
Operation 81-73 brings the car back to the main level or replacement level as soon
as at least one level is stricken.
The input “TR1M-CPO 216SP” board be used to inhibit the fire plant operation and
force the lift to restart.
[DESACTIVATED] [EN81-73 STANDARD] [U36/G36 STANDARD]
DETECTION
Type of fire detection
The inputs for detection of stricken floors are on the 217SP board.
Output X1 for landing 1 up to X24 for landing 24
If the installation has indicator lights, the stricken floors are on the second expansion
board.
The input “MANUAL CALL” is on TR1M-CPO 216SP board
[STRICKEN FLOORS] [MANUAL CALL]
SECURE FLOOR
Fire security floor
Security floor where the car goes if the fire operation is engaged.
[0..31]
SUBSTITU. FLOOR
Substitution floor
If the “fire security floor” is stricken, a second level is configurable for evacuating
users
[0..31]
DOOR OPEN
Parking door open
[NO] [YES]
