1.5 What’s new since 5-20 software version
1.5.1 New functions
K05SP Car positioning system
This new car positioning system K05SP is an absolute linear shaft reader. Position is written on the encoded
stainless steel tape mounted from top to bottom of the shaft
The main assets of this reader :
1 mm precision.
very compact housing.
extremely simple assembly.
Sam shaft’s learning procedure as K04SP.
Very silent even at high speed
The choice of this reader appears in the following menu : CONFIGURATION ► CAR POSITION ►READER
Out of Use operation with doors opened
It’s now possible the car stands still with doors opened while the lift is in Out of Use operation,
It can be chosen in the following menu : CONFIGURATION ► BUILDING ► OOU.DOORS.OPENED
New floors indications selection
With 232 , 236 and 262 displays , the following indications have been added to the list :
0/1 , 1/2, 2/3 , 3/4 , 4/5 , 5/6, 6/7 , an 7/8
It can be chosen in the following menu : CONFIGURATION ► INDICATION ► FLOOR/DISPLAY.
Construction year
This parameter is only for informative purpose and shall be set to the construction year of the lift. This
construction year will be then displayed next to the CE mark on the load plate of the 236SP1 display.
If the year is set to 0, nothing will be displayed.
This setting can be found in the menu : CONFIGURATION ► IDENTIFICATION ► CONSTRUCT. YEAR
New supervision output "CALL °PENDING".
This output is activated as soon as an user request (car call or hall call) is currently pending or in progress ;the
output is reset as soon as there are not any user calls anymore or in case the lift is not in user mode.
It can be chosen in the following menu : CONFIGURATION ► I/O BOARDS ► 217SP► I/O REMOTE
Hoistway access detection
The hoistway access detection sets the lift out of order, in the case a landing door has been detected opened for
longer than 8 seconds (thanks to the landing doors safety locking contact), out of a normal car parking in user
mode. The presence of a technician is mandatory to set back the lift in user mode.
This detection only occurs in user mode
Caution : this detection can’t operate properly with a lift compliant to EN81-20 standard , as in that case the
landing doors are always unlocked when the lift is idle in user mode.
This detection can be enabled in the menu CONFIGURATION ► OPERATIONS ► HWAY.ACC.DETECT.
1.5.2 Modifications
Modification of the procedure after pit inspection
The procedure defined in the ASP116 EVOLUTION to put back the lift in service after exiting the pit inspection
mode, has been simplified. It is fully detailed in the installation (ref. B-DP-13-006 Annexe 2-5).
This procedure is valid only if the following parameter :
CONFIGURATION ► EQUIPEMENT ►REARM.INS.CUV. is set to [BY ASP116-EVO] (voir 2.6)
Door Bypass Device activation
The user mode is set of use as soon as the Door Bypass Device is activated .
Music in car
The playback of the music in car is stopped as soon as an emergency phone communication is detected. For
that, the 230SP board is needed, as the yellow/green indicators outputs of the phone are connected on this
board ; and the controller uses its states to detect the use of the emergency phone.
