4.4.4 Car boards
CAR BUS
OO
COMM. BOARD 211
Communication error with 211SP board
CANbus communication between the car (211SP board) and the machinery (216SP board) is not operating
correctly
- Check the CN5M / 216SP connector and PE1 / 211SP connector
- Check cabling in inspection box. Ensure that the high voltage wires do not go over the top of the
211SP board.
- In case of door control by 380V, ensure that the 69SP filters are connected
OO
211SP REPROGR.
Error on car roof 211SP board programming
- Make a new software update of the control panel
- Change the 211SP board
OO
211SP VERSION
The software version of the 211SP car is wrong
- Make a new software update of the control panel
ALARM
COMM 230 SP #XX
Communication error with 230SP board
CANbus communication between the car (230SP board) and the machinery (216SP board) is not operating
correctly
- Check the CN5M / 216SP connector and CN1 / 230SP connector
ALARM
230 #XX REPROGR.
Error on 230SP Bluetooth board programming
- Make a new software update of the control panel
- Change the 230SP board
ALARM
230SP #00 VERS.
The software version of the 230SP car is bad
- Make a new software update of the control panel
ALARM
230SP #XX SAME ID
The both 230SP boards have the same Canbus ID
- Make a new software update of the control panel
ALARM
COMM. FLEXYPAGE #X
Communication error with flexyPage (#1 or #2)
- Check the CAN bus connection of the flexyPage
4.4.5 Floor boards
FLOOR BOARDS
ALARM
COM BOARD N°XX
Communication error with a floor board
The 216SP board meet some communication error with a floor board
- Verify the connectors
- Change the 228SP or 137SP board
ALARM
WRONG VERS. N°XX
Wrong software version of the floor board
The software version of the floor board is not compatible with the control panel software.
