2.21.1 Configuration of K04SP / K05SP
Configuration of the flags with a standard inverter
SLOWDOWN FLAG
Relative position of the slowdown flag
[0..300] centimeters
UP STOP FLAG
Position of up travel stop flag
[10..100] centimeters
DOWN STOP FLAG
Position of down travel stop flag
[10..100] centimeters
Configuration of the flags for ATV LIFT inverter with CANbus :
SHIFT SLOWDOWN
Shift the lift controller slowdown flag compared to the deceleration distance
of the inverter
It is possible to advance a little bit the lift controller SHIFT SLOWDOWN in order to
increase the slowdown area. The lift will be less efficient but the stop precision will
be increase in open loop.
[0..100] millimeters
SHIFT UP STOP
Shift the lift controller up stop flag compared to the inverter stop distance
[-127..127] millimeters
SHIFT DOWN STOP
Shift the lift controller down stop flag compared to the inverter stop distance.
[-127..127] millimeters
Standard configuration
FLOORS POSITION
Absolute position of the floors (PALIER 0 to PALIER 31)
[0..150] meters
DOWN SLOWDOWN
Relative position of the “down slowdown flag” for near floors movement
[0..300] centimeters
UP SLOWDOWN
Relative position of the “up slowdown flag” for near floors movement
[0..300] centimeters
