MANUEL D’UTILISATION « ASP 116 EVOLUTION »
Sprinte SAS, All rights reserved, including translation rights
4.3 Diagnosis menu
Indication of errors encountered during lift operation. All anomalies encountered during lift operation are recorded
and can be consulted in this menu.
Recording of last twenty faults. Each fault is numbered from 1 to 20 from the oldest to
the most recent.
INFORMATIONS ON INVERTER OPERATION
(Only with « ATV71L BUS » see §2.10.1)
- Speed, motor current, output frequency measured, main voltage.
STATUS OF MULTIPLEX BUS CONNECTIONS
Gives indications on operational status of multiplex bus.
Each lift has a status:
0 => not connected 1 => connected
STATUS OF CONTROL PANEL’S SERIAL LINKS
Gives indications on operational status of communications
CN1 (RS485), CN2 (RS485), CN5 (CANBUS), CN6 (CANBUS), CN7 (CANBUS),
CN11 (217SP expansion board)
TEMPERATURES DETECTED BY 132 PK SENSORS
Depending on number of sensors, this menu displays current temperature of
216SP SENSOR and machine room sensor
Gives information on lift use
Counter of number of starts
Date of last power failure
Rope wear counter
State of Safety contacts inputs
State of 220SP board inputs outputs
State of 211SP board inputs outputs
State of 223SP board inputs outputs
Display of low voltage on the 211SP
