4.4.2 Lift
LIFT
ALARM
STRICKEN FLOOR
One or more levels are stricken
- Check inputs on 217SP board
ALARM
FIRE CALL
The lift is called by the firemen
Check manual call input CPO-216SP and stricken levels
4.4.3 Control panel
CONTROL PANEL
OO
217SP N°XX OO
217SP extension board is out of service
The control panel no longer manages to interact with 217SP expansion boards.
- Check that the configuration switch is in the correct position
- Check the connector CN1/ 217SP then do a reset.
- If the problem persists, change the 217SP then 216SP board.
OO
223SP N°XX OO
223SP extension board is out of service
The control panel no longer manages to interact with 223SP extension boards.
Check the connector CN3 /223SP, do a reset, change the 223SP then 211SP board.
XX = 00 for board with SW1 1 =OFF
XX = 01 for board with SW1 1 =ON
OO
MACHINE BUS OFF
Frequency inverter bus is cut off
Serial communication with the frequency inverter is cut off.
- Check CN6M / 216SP
- Check the CANopen connector of the frequency inverter
- Change 216SP board
OO
MULTIPL BUS OFF
Multiplex bus is cut off
Serial communication between the machinery board (216SP board) and the other 216SP boards of other
battery control panels is cut off
- - Check CN8M / 216SP
- - Check the presence of resistors at the each extremities of the multiplex bus
OOM
WINCH BOARD
Communication fault with winch board 220SP
Serial communication between the machinery board 216SP and the winch board 220SP
- Check CN4M/216SP
ALARM
FAULTY SD
Files error on SD card
The controller is not able to write files on the SD card due to deficient sectors found.
The Lift is still working but it’s not possible to modify any settings.
- Change the SD card and contact our AfterSales department in order to recover your files.
ALARM
SD WRITING
Files error on SD card
