USER MANUAL « ASP 116 EVOLUTION »
CONFIGURATION
Sprinte SAS, All rights reserved, including translation rights
55
3 0x4 0000 0010
4 0x6 0000 0110
5 0x7 0000 0111
6 0x5 0000 0101
7 0x6 0000 0100
../..
3.4 Configuration I/O supervision
CONFIGURATION ► I/O BOARDS ► 217SP
To assign the connectors to I/O REMOTE, the following parameter must be configured:
[CONNECTOR] = [I/O REMOTE]
ES1-X, ES2-X
ES3-X, ES4-X
Entry options
[>AUTO MOVEMENT]
Generates car’s travels at all levels
[>GOTO TOP FLOOR]
Generate a call to the highest floor
[>GO LOWEST FLOOR]
Generate a call to the lowest floor
[>OPEN DOOR 1]
Open door 1
[>OPEN DOOR 2]
Open door 2
[>REMOTE RESET]
Reset the lift controller
ES1-X, ES2-X
ES3-X, ES4-X
Output options
Powers state
[<CAR LIGHT FAULT]
Indicates a fault on the Car light
[<POWER FAILURE]
Main power supply is off
[<PHASE ERROR]
Fault on one phase of the main power supply
Safety chain state
[<S.CHAIN CLOSED]
The safety chain is closed (VERR)
[<LOCKING FAULT]
Fault with the locking contact of the landing doors
[<CAR S.CHAIN]
Car door is closed (SHC)
[<FLOORS S.CHAIN]
Floors doors are closed (SHP)
[<PASSIVE S.CHAIN]
Passive safety (STOP, LIMITER, SAFETY GEAR )
[<ALIM. S.CHAIN]
Safety chain is powered
Elevator operating mode
[<OVERLOAD]
Lift is in overload
[<OUT OF USE]
Lift out of service
[<EMERGENCY OPERA]
Lift in emergency operation
