USER MANUAL « ASP 116 EVOLUTION »
Sprinte SAS, All rights reserved, including translation rights
Main advantages:
- Only one flat cable
- MP3 speech synthesizer
- Security chain pre-wired
- Configuration and application software saved on the SDCard
- 2 lines * 20 characters LCD display
- All defaults saved on the SD-CARD
- Time and date of the faults
- Control of Machine room temperature
- Voice assistance for the technical
1.1 Safety instructions
1) The control panel must be installed in a dry, clean room and only accessible to authorised staff.
2) The room temperature must not exceed 40° and must be greater than 0°
3) The lift must be taken out of service if the two-way communication system is not working
1.2 Mechanical characteristics
Cabinet size:
The cabinet size can vary according to options
The control panel weight varies between 25Kg and 100Kg according to power
1.3 Electrical characteristics
The control panels are serial equipped with a protection system against lightning and all the contactors are
installed on Silentblocs in order to reduce noise emission outside the control panel
220Vac / 230Vac single phase or three phase, 380Vac /
400Vac three phase
24V full-wave 2A, 55V / 70V full-wave 4A, 110Vac / 1A, 220V
“220F” /2A
Battery 12V / 2,1Ah or 7,1 Ah
Inputs / outputs single wire, earth return, voltage 24V
continuous
Type of indication (LED or light 24V / 50mA max)
This manual describes the functions of the software V04.06. It is possible that older versions of
software do not have all the features described. Check the version of the software before you
start reading the manual.
