2.22 Car load controls
CONFIGURATION ► CAR LOAD
LIFT CAPACITY
Car nominal load in kilograms
This value is displayed on the 236SP if chosen in the display settings (see §2.19.1)
[0…9999] kg
NB. OF PEOPLE
Car nominal load in number of persons
This value is displayed on the 236SP if chosen in the display settings (see §2.19.1)
[0…99]
OVERLOAD
Car overload detection
[NO DETECTION] [PE2M-SU / 216SP] [CB7-SU / 211SP]
NON STOP FULL
Non stop full detection
[NO DETECTION] [PE2M-NSC / 216SP] [CB7-NSC / 211SP]
2.23 Overspeed monitor for machineroomless lifts.
CONFIGURATION ► OVERSPEED
This menu is displayed only in case of K04SP/K05SP shaft reader (see §2.21.1). Nevertheless the overspeed
monitor is also displayed in case of Closed – Loop motor control by the inverter
The overspeed monitor watches the speed of the car in every operation mode of the Lift.(user, out of power,
maintenance). The speed and direction of the car are displayed as soon as the lift switches in ‘OUT OF POWER’
mode.
With a K04SP reader the lift will become ‘Out of Order’ whether
- The car speed exceeds the nominal speed in user mode.
- The car speed exceeds the rescue speed in out of power mode.
- The car speed exceeds the maintenance speed in inspection mode.
- No datas is received from the K04SP/K05SP reader while trying to move.
DETECTION
Overspeed monitor
[NO] [YES]
RATED SPEED
Nominal speed of the car
With a K04SP the lift will be set out of order if the car speed exceeds 15% this speed
[0.01..2] m/s
EMCY SPEED
Maximum speed of the car in out of power mode.
This speed shall be set during the installation of the lift, with tests in out of power
mode. The overspeed indication ‘OS’ will be displayed if this speed is 10%
exceeded.
[0.01..2] m/s
Speed indication
Overspeed indication
SPEED : 0.75 OS
DIR.: UPWARD R
« R » Rescue mode
indication
Direction indication
