USER MANUAL « ASP 116 EVOLUTION »
Sprinte SAS, All rights reserved, including translation rights
2.12.1 Lift information
CONFIGURATION ► FREQ. INVERTER ► LIFT DATAS
Car rated speed at nominal motor frequency (CSP)
The car rated speed corresponds to the linear speed of the lift car when the motor
runs at its rated speed.
Capacity of the lift (LCA)
The payload corresponds to the maximum permissible load in the lift car. It must
always be stated in the lift car (for example: 630 kg - 8 persons)
Acceleration comfort (ACM).
This parameter defines the maximal acceleration and deceleration authorized during
the movements of the lift.
[0,1..2] m/s2 par défaut 0,8 m/s2
The travel speed corresponds to the linear speed of the car in steady state (high
speed).
The acceleration time corresponds to the time the car will take to attain its “Lift top
speed”
The stop length corresponds to the distance separating the stop indicator from the
step the car is destined to reach.
Lift leveling speed (LLS).
The lift leveling speed is calculated by the drive automatically. If the calculated speed
is not suitable (because it corresponds to a mechanical resonance frequency for
example), it can be re-entered manually. In this case, the lift leveling time should be
recalculated.
The lift leveling time corresponds to the time the car will spend at lift leveling speed in
steady state.If the lift leveling time is too short, the ride will be uncomfortable (rolling
sensation).If the lift leveling time is too long, the ramp between LtS and LLS will be
intense (loss of comfort).
Deceleration length (dEL)
The slowdown length corresponds to the distance separating the slowdown indicator
from the floor the car is destined to reach.
