4.4.7 K04SP/K05SP
K04SP/K05SP
OO
DIAL COM
The com can’t be established with the reader
- Check CB11 / 211SP
- Check that the cable is not near a power cable
OO
ERR. POSITION
Floors position error
- Restart a shaft learning procedure
OO
OUT OF WORK AREA
The reader is out its work area
- Remake a reader calibration at each floors
OO
BATTERY
The battery is out of services (K04SP only)
- Replace the K04SP
OO
TEMPERATURE
The temperature is too high (K04SP only)
- Check the reader temperature
4.4.8 Safety chain
SAFETY CHAIN
OO
CHAIN POWER
Safety chain power supply fault
- Check the safety chain power supply
- Check the fuse CHS on the 214SP board. The CHS LED must be ON
OO
EMERGENCY STOP
Lift in emergency stop
- Check the primary safety chain :
MACHINERY STOP, STOP RECESS, PARACHUTE, SPEED GOVERNOR, TENSION PULLEY
ALARM
EN COURT CIRCUIT
The chain may be short circuited
On door opening, the control panel has not detected the disappearance of SHUNT or LOCKING.
- Check that the doors open when they are commanded
- Check opening of the shunt in automatic door and locking in manual door during opening
- Check the door opening time
OOM
END LIMIT SWITCH
Lift at end limit
- Check the distance of DHCS contact hydraulically
- Check the distance of FCH and FCB contacts electrically
OO
SH TOE GARD
Shunt toe gard
The retractable toe-gard is permanently shunted by the cam « detect 1m » that is at the bottom level.
- Check the switch.of the cam « detect 1m »
ALARM
SHUNT
SHUNT detection problem
