USER MANUAL « ASP 116 EVOLUTION »
CONFIGURATION
Sprinte SAS, All rights reserved, including translation rights
41
2.19 Visual indications
CONFIGURATION ► DISPLAYS
2.19.1 Visual indications in car
CONFIGURATION ► INDICATION ► CAR
DISPLAY
Display type
[NO DISPLAY] [61SP/63SP] [122SP/123SP] [LCD WECO]
[232SP COLOR] [235SP BLUE] [236SP COLOR] [FLEXYPAGE]
FLEXYPAGE NB
Number of flexyPage in car. (only if DISPLAY = FLEXYPAGE)
As the flexyPage display is mastered by the controller on the CANopen bus, it shall be
informed how many are connected on.
[0..2]
LOAD PLATE
Informations to display on the load plate of 236SP
(only with 236SP)
[NON] : No load plate on the display.
[1 : NOM LOAD] : Nominal load of the car and number of persons.
(Set both values in menu CONFIGURATION -> CAR LOAD)
[2 : 1+SERIAL NB.] : NOM LOAD + Serial number of the lift
(Set the value in menu CONFIGURATION -> IDENTIFICATION)
[3 : 2+ CE MARKING] : NOM LOAD + SERIAL NB+ CE marking with symbol
(Set the value in menu CONFIGURATION -> IDENTIFICATION)
CUSTOMER LOGO
Display of the customer’s logo on the 236SP
(only with 236SP)
[YES] [NO]
ORIENTATION
Select the 232SP display orientation
(only with 232SP)
[LANDSCAPE] [VERTICAL]
1 BKGND/FLOOR
(only with 236SP)
The background of 236SP is associated with each level.
On level 0 , file 001.BMP is displayed ; on level 1 , file 002.BMP; on level 1 , file
003.BMP etc....
The parameter « BACKGROUND PIC.» (see below) won’t be available anymore.
[YES] [NO]
BACKGROUND PIC.
Select background display
(232SP and 236SP)
 232SP : [BLUE] [RED]
 236SP : [SLIDESHOW], [FILE 001.BMP]… [FILE 028.BMP]
Choose a specific image file for the background or a slideshow of the
28 image files available
SLIDESHOW TIM.
Time for the display of an image in slideshow mode
(only with 236SP)
[1min], [3min], [5min], [10min], [15min], [30min], [1h], [3h], [5h], [10h], [24h]
TIME AND DATE
Displays the time and date
(232SP & 236SP)
[YES] [NO]
LAST VISIT
(only with 236SP)
Displays the date of the last maintenance visit.
This date has to be updated in ASSISTANCE-> VISITE DONE.
[YES] [NO]
