3.5 I/O configuration of the bus floors (228SP, 137SP)
CONFIGURATION ► ► I/O BOARDS ► FLOORS BOARDS
Configuration of the landing buttons. The boards are identified from 0 to 24.
LEVEL
Level assigned to the landing board
[0..32]
DOOR
Door assigned to the landing board
[DOOR 1] [DOOR 2]
LIFT 1 2 3 4
Lift affected to the landing board
ASC 1 2 3 4
[0 0 1 0] (the board is associate to lift n°3)
CN4, CN5-E1, CN7
Landing buttons
[NOT CONNECTED] [CAR CALL] [UP FLOOR BUTTON] [DN FLOOR BUTTON]
[FIREMAN KEY NC] [FIREMAN KEY NO] [SET OUT OF USE] [H.CALLS DISABLE]
CN5-S2, CN5-S3
Special output at the floor
[NOT CONNECTED] [MOVING UP][MOVING DOWN]
[CAR AT LVL IND] [OUT OF USE]
