MANUEL D’UTILISATION « ASP 116 EVOLUTION »
Sprinte SAS, All rights reserved, including translation rights
Cell detection error door area
- Check the reader’s “cell C”
This fault makes a car repositioning for reader calibration.
- Check the placement of the counting flags
- Check the reader position
- Check flag position with sequences imposed by the configuration (Crosse-over, close levels)
The reader 224SP is out of service
- Check the configuration matches the reader in place.
- Check connection of DTC inputs, C, A, B on CB3-211SP connector (a disconnected wire on one of
the inputs causes a DTC error).
- Check operation of 224SP reader
Reader recalibration error
Check flags, sensor installation and state of rockers or ILS of top and bottom decelerators.
Check flags, sensor installation and state of rockers or ILS of top and bottom decelerators.
XX = A : Check cell A is operating correctly
XX = B : Check cell B is operating correctly
XX = AB : Check cells A and B are operating correctly
Loss of door area while car is stopped
The doors are closed automatically if the “DOOR AREA” signal is lost during opening or when stopped
- Check the cell C for a magnetic selection, check the distance between the sensor and the magnet
- Check the position of the door area screen for an optical selection.
- Check the operation of 224SP optical reader.
Door opening request outside area
The car wanted to open its doors without the door area being detected.
.
- Check the reader, check the door area, check the safety chain
The door area is always active.
The door area information is always active on the controller, whatever the car position .
- Check cell C for magnetic reader.
- Check the operation of 224SP optical reader.
