USER MANUAL « ASP 116 EVOLUTION »
CONFIGURATION
Sprinte SAS, All rights reserved, including translation rights
43
2.19.2 Visual indications on floors
CONFIGURATION ► INDICATION ► ON FLOORS
CONFIG.FLOORS
Sub-menu for configuration floor by floor (see table on next page)
(Only if there are landing boards with your equipment installation AND no flexyPage
are used on floors)
 Display type
 Floor indication
 Specific options of the display
ENTER >>
[ON FLOOR 00]… [ON FLOOR 31]
216SP DISPLAY
Display connected on 216SP Board
Output AFT-TR3M on 216SP board , for 61SP/122SP/ LCD WECO displays type.
Output CN1-M on 216SP board for 235SP/232SP/236SP displays type.
[NO DISPLAY] [61SP/63SP] [122SP/123SP] [ LCD WECO]
[232SP COLOR] [235SP BLUE] [236SP COLOR]
FLOOR/DISPLAY
Choice of indication to display at each floors
Display possibilities depend on the display type
ENTER >>
See appendix for available display depending on the display present in the
equipment
FLEXYPAGE NB
Number of flexyPage on floors.
As the flexyPage display is mastered by the controller on the CANopen bus, it shall
be informed how many are connected on.
[0..2]
TIME AND DATE
Displays the time and date
(232SP and 236SP)
[YES] [NO]
CUSTOM LOGO 236
Display of the customer’s logo on the 236SP
(only with 236SP)
[YES] [NO]
236 BCKGND PIC.
Select background display for 236SP
(only with 236SP)
[FILE 001.BMP]… [FILE 028.BMP]
Choose a specific image file for the background .
232 BCKGND PIC.
Select background display for 232SP
(only with 232SP)
[BLUE] [RED]
ORIENTATION
Select the 232SP display orientation
(only with 232SP)
[LANDSCAPE] [VERTICAL]
ARROWS
Arrow type
Outputs TR3M FD, FM / 216SP for traditional wiring
[NO ARROWS] [61SP/63SP] [122SP/124SP] [DIRECT]
ARROWS INDIC
Arrow indications
The arrows have to be arrows for moving in blocking
[MOVEMENT] [NEXT DEPARTURE]
BUTTON FLASHING
Buttons flashing during movement
[NO] [YES]*
