5.3.2 137SP landing board with voice synthesizer
CN1 CANBus input
CN5 Display
>1
24 V DC
<1
24 V DC
>2
CANBUS 0 HIGH
>2
S3
>3
CANBUS 0 LOW
>3
S2
>4
GND
>4
S1
CN3 RS485
<5
GND
<1
24 V DC
CN6 CANBus output
>2
485H
<1
24 V
>3
485L
<2
CANBUS 0 HIGH
4
GND
<3
CANBUS 0 LOW
CN4 landing button 1
<4
GND
<1
24V DC
CN7 landing button 2
<2
BP1
<1
24V DC
>3
LED
<2
BP2
<4
GND
>3
LED
<4
GND
CN8 Landing door
CN11 Speaker
<24 V
24 V DC
GND
HP
<SINH
Blocking door
<HP
HP
>EPOR
Landing door state
<GND
GND
CN9 Door alarm
<24 V
24 V
<SSIR
Alarm output
>EARM
rearmament
<GND
GND
