USER MANUAL « ASP 116 EVOLUTION »
Sprinte SAS, All rights reserved, including translation rights
2.21 Car positioning systems
CONFIGURATION ► CAR POSITION
[224SP/211SP] [K04SP] [SENSORS/211SP][K05SP]
Settings for flags’ reader systems (224SP, SENSORS)
BY DECELERAT : flags are automatically set according the to kind of deceleration
flags for each level (see below DECELERATION FLAG)
BY SCREEN : flags have to be completely set separetaly .Choose this flag
configuration , only if you can’t use the configuration BY DECELERATOR
[BY DECELERAT.] [BY SCREEN]
Adjustment of deceleration flags for each level
Depending on the distance between landings and the car speed, the deceleration
flags need to be configured
[NORMAL] [CROSE-OVER] [CLOSE LEVELS]
Adjustment of each deceleration flag.
Every single flag has to be configure separately : choose first the kind of flag (Top
Decelerator TD, level stop LVL or Bottom decelerator BD), then choose the
associated level ( [xx] )
High speed inter floor movement timer
This timer is used to set a high speed setting time between two levels if the car keeps
in low speed for a too long time due to the deceleration flags position
Rise time for the cab before reader calibration phase
This delay serves to raise the car enough to reach its high speed before detecting
the low speed limit switch
RESET SKIDDING
In some case with a 224SP reader, if where there is a big distance between floors
or if the lift is a very low speed lift, the SLIDDING security can be set if the travel
time without seeing a flag is superior to 20 sec.
To avoid this, it is necessary to activate this option and to plug a magnetic finger to
the input DTC of the 211SP board.
