USER MANUAL « ASP 116 EVOLUTION »
Sprinte SAS, All rights reserved, including translation rights
Doors with limit switch opening
Presence of thermal protection for door motor
The presence of this protection will enable the management of the door’s motor
overheat monitoring
Probe for Door 1 : input CB4-I1 / 211SP
Probe for Door 2 : input CB4-I2 / 211SP
Management of the retiring cam device to unlocking the landing doors.
The cam is automatically released if the car is stopped.
Connector door 1 « CAM 1-CN11-I / 220SP »
Connector door 2 « CAM 2-CN9-I / 220SP »
The cam can be released either before or after opening doors.
In case of cam released before door opening, “TP CAM RELEASE” time gives a
delay between cam release and door opening.
In case of cam released after door opening, “ TP CAM RELEASE” gives a delay
between door opening and cam release.
[BEFORE OPENING] [AFTER OPENING]
Temporisation of cam release for landing doors unlock.
[1..30] tenth of seconds.
