The closing command is stopped by “closing limit switch” or end of timer.
[2..45] seconds
OPENING TIMER
Maximum door opening time
The opening command is stopped by “opening limit switch” or end of timer.
[2..45] seconds
PARKING TIMER
Car parking time with door open
Time during which the car stays with door open to let users exit and enter in car
Shorten time:
Automatic door: Press car button “Door closing”
manual door : Closing landing door
[2..20] seconds
TMR ON REOPENING
Car stopping time when reopening
In case of reopening of the door because of a shock or alight barrier event, the door
will be kept opened during this following value :
[1..10] seconds
TP DEBOUNCING SH
Temporization of shunt debouncing on floor doors
This temporization is launched once the floor door is closed.
With manual landing doors, this temporization delayed the car door closing
With automatic landing doors, this temporization delayed the reopening of the doors
caused the de shunt debouncing.
[0..3] seconds
PHOTO CELL
Door closing protection by cell
Causes reopening if the cell is cut and the car is in a door area and closing with
nudging if the car is outside of door area. This protection is not active if the door is
closed.
DOOR 1 : [NO] [CB8 / 211SP-24Vdc] [CB19 / 210SP-220Vac]
DOOR 2 : [NO] [CB36 / 223SP-24Vdc] [CB16 / 210SP-220Vac]
DOOR SHOCK
Door closing protection for shock
Complete reopening of doors if a shock is detected during closing. Doors remain
open if closing was not possible after several attempts and while input is active.
Connector « CHC1-CB8 / 211SP »
[NO] [YES]
CLOSE BUTTON
Accelerated closing of doors button
Connector « FAC1-CB1 / 211SP »
[NO] [YES]
REOPEN BUTTON
Door reopening button
Connector « OAC1-CB1 / 211SP »
[NO] [YES]
CLOSING SWITCH
Doors with limit switch closing
[NO] [YES]
